FTTX MTP MPO OM4 OM3 G652D Fiber Optic Fanout Cable

12 Core MTP MPO Multimode OM4 OM3 Plenum 50 Fiber Optic Fanout Cable

Specification:

PERFORMANCE INDEX
MPO CONNECTOR
Fiber type	SM		MM
	UPC	APC	PC
Insertion Loss (IL)Low(dB)	≤0.35		≤0.35
Insertion Loss (IL)Max(dB)	≤0.75		≤0.6
Return Loss (RL)(dB)	≥50	≥60	≥20
Endurance (500 remates)(dB)	IL<0.3		IL<0.2
Operating Temperature(℃)	-10 ~ +60
Storage Temperature(℃)	-40 ~ +85
Maximum tensile strengthe(N)	100

Description:

MPO/ multi-fiber cabling system is ideally suited for a high density environment that demands space saving and innovative cable management solutions. MPO fan-out supports various connections from multi-fiber to single-fiber out. We also offer various other MPO products such as MPO cassettes, modules and enclosures. These cassettes provide secure transition between MPO and LC or SC connections.

Features:

1.High repeatability & credibility
2.Competitive price
3.Fast delivery time
4.Low insertion loss

Applications:

1,Optical fiber communications systems;
2,Optical fiber access network;
3,Optical fiber CATV.
4,Optical fiber test equipments;
5,Optical fiber data communications;
6,LAN
