    Metal Plastic APC SC Shutter Adapter Single Mode 0.2dB For CATV

    Singlemode Blue Color Metal Shutter Plastic Housing SC Outer Shutter Adapter

    This SC Adapter with Outer Shutter is designed to cover the entire coupler hole. These unique adapters virtually eliminate eye exposure to lasers and provide maximum protection from dust and other contaminants. The swing shutter automatically opens as the SC connector is inserted, and closes as it is extracted.

    Fiber optic adapter is also called fiber optic coupler. It is used to provide a cable to cable fiber connection. People sometimes also name them to be mating sleeves and hybrid adaptors. Mating sleeves means this fiber optic adapter is used to connect the same type fiber optic connectors, while hybrid adaptors are the fiber optic cable adaptor types used to connect different kinds of fiber optic connectors. We provide a complete line of adapters for fiber optic connection, like ST, SC, FC, LC, MTRJ, MPO, MU, SMA, E2000, DIN style fiber optic adapters for both multimode and single-mode fiber applications.


    SC Outer Shutter Adapter Specifications:


    ItemSC Outer Shutter Adapter
    ModeSinglemodeMultimode
    Housing ColorAPC=Green,PC=BlueBeige / Aqua / Violet
    Main Body MaterialPlastic
    SleeveZirconia
    Typical Insertion Loss(dB)≦ 0.15dB
    Durability< 0.2dB change, 500mating
    Operating Temp.-40℃ ~ +75℃
    Storage Temp.-40℃ ~ +85℃

    SC Outer Shutter Adapter Features:


    • Simplex and Duplex model available
    • Low insertion loss
    • Easy installation
    • Diversity - Blue, Green, Beige, Aqua. Black and Magenta are available under request
    • Availablein both flange type and no flange type configurations


    SC Outer Shutter Adapter Application:


    • Telecommunication networks
    • Local Area Networks (LANs)
    • CATV
    • Industrial, military and medical

    Internal & Outer Shutter Adapter Pictures:

    Metal Plastic APC SC Shutter Adapter Single Mode 0.2dB For CATVMetal Plastic APC SC Shutter Adapter Single Mode 0.2dB For CATV
