12Fiber 900um Buffer Tube SC/UPC G657A Singlemode Optical Pigtail
Patch Cord Fiber Optic
Applied range
1 Optical fiber communication system
2 Optical access network
3 Optic-fiber Date Communication
4 Optical-fiber CATV
5 A local area network (LAN)
6 Test Equipment
Order informations
HYG-ST/ PC – ST/ PC/ SM/ 2C/ 3.0 – 1M
1 2 1 2 3 4 5 6
1 Connector types: FC, SC, LC, ST, MTRJ, MU, MPO, DIN, D4, SMA
2 Ferrule End-face: PC, APC
3 Fiber Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or
62.5/125um)
4 Cable Quantity: “2C” means duplex,C means simple
5 Cable Diameter: 3.0mm, 2.0mm, 0.9mm
6 Length:1, 2, 3 meter or customized length
7 Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
Technical parameters
1 The min bending radius: 3.8 cm
2 Operating temperature range: - 40 ~ 85 °C
3 connector materials: ceramic plug core
4 Min bandwidth: 200 MHZ. Km / 850 nm, 500 MHZ. Km / 1300 nm
5 Repeat plug: < 0.2 dB, each 500 times plug
6 Min reflection loss: 20 db
7 Max return loss:-50dB
ITEM | TEST conditions | Single mode | Multi mode |
Optical properties | Insertion loss | UPC | 1.31um,LED | <=0.3dB | <= 0.3dB |
APC | 1.31um,LED | <= 0.3dB | <= 0.3dB |
Return loss | UPC | 1.31um,LED | >=50dB | >=35dB |
APC | 1.31um,LED | >=60dB | |
Mechanical properties | Impact test | HIGH:1.8 8 TIMES | <0.1dB | <0.1dB |
Vibration experiment | 5-50HZ,1mm Full amplitude | <0.1dB | <0.1dB |
Plug life | More than 1000 times | <0.1dB | <0.1dB |
tensile strength | >100N, | <0.1dB | <0.1dB |
Environment characteristics | Temperature Cycling Test | -25°C~+70°C,5 circle | <0.2dB | <0.2dB |
high-temperature test | +80°C,100 hours | <0.2dB | <0.2dB |
Low-temperature test | -40°C,100 hours | <0.2dB | <0.2dB |
Damp and hot test | +25°C~+65°C,Relative humidity 93%,100 hours | <0.2dB | <0.2dB |
Environmental Reliability Test
The performance of the patchcords has been carefully designed to
meet the IEC standards, GR-326-CORE, in the test of optical
characteristics, vibration test, thermal cycling, impact
resistance, salt spray erosion, thermal aging, humidity resistance
and others
Other types of FO pigtails
